DENEB UNIVERSAL BALL SORTER

With a small footprint and an ability to handle all product shapes, sizes and types, our Universal Ball Sorter is an ideal solution to handle high volume SKUs in e-commerce, logistics or warehousing centers. The items moving on the Universal Ball sorter rest on the free-spinning angled rollers which selectively gets activated and divert the moving items to the left & right directions.

The sorter can handle fragile items, parcels, cartons, totes, books, polybags and other items which are difficult to be handled by a conventional linear arm, narrow belt or steerable wheel sorter.

Universal Ball Sorter Technical Specifications
Throughput2000 PPH
Sorting directionBi-directional
Sorting angle30 degree/90 degree
Product dimensions100 x 100 mm (min)
1200 x 1200 (max)
Min. Gap between items100 mm
Max. load capacity50 kg/m
Conveyor speed30 m/min
Max Weight50 kg

USP’S OF NIDO’S UNIVERSAL BALL SORTER

  • Sort upto 2000 parcels per hour

  • Suitable for any industry

  • Extremely Gentle Product Handling

  • Reduced labor requirements and Improve accuracy

Introducing Our DENEB Universal Ball Sorter !!

This System used for sorting material on Left & Right hand direction of the conveyor. These Conveyor is suitable for achieving high sorting throughput.

It can sort upto 2000 parcels per hour and can handle a large variety of product shapes, sizes and types. The items moving on the Universal Ball sorter rest on the free-spinning angled rollers which selectively gets activated and divert the moving items to the left & right directions.
